OBD2 scanner ELM327 for car diagnostics

OBDII-Bluetooth – a modern adapter for car diagnostics. The Bluetooth adapter is connected to the OBDII connector, and power is supplied from it. The device is intended for express diagnostics of a car based on a PC, tablet, Android, smartphone, mobile phone, GPS navigator, etc. Scanners based on the ELM327 controller have a good reputation among motorists. A huge advantage is the fact that the device is compatible with programs that are freely available on the Internet. A lot of functionality is provided by such programs as: VitalScan, TorquePro, hobDrive, PcmScan, ScanMaster, Proscan and others. The adapter supports all OBD-II protocols and works with all OBD-II compatible cars, that is, it covers the entire range of modern passenger and commercial vehicles produced after 1996 in the USA, in Europe - since 2001, gasoline cars since 2003/2004. , diesel cars.

Operating principle of OBD2 scanner ELM327:

The device communicates with your PC, laptop, PDA, tablet, smartphone, telephone and even GPS navigator via the Bluetooth communication interface.

Features of the OBD2 ELM327 Bluetooth adapter:

- Reads errors

- Erases errors

- Shows fuel consumption

- Displays parameters of vehicle systems and sensors in real time:

Engine speed;

Engine load;

Coolant temperature;

Fuel system condition;

Vehicle speed;

Long-term fuel consumption;

Absolute air pressure;

Ignition advance;

Intake air temperature;

Mass air flow;

Throttle position;

Lambda probe;

Fuel pressure, etc.

- Acceleration time counter: from 0 to 100 km/h;

- Takes a freeze frame;

- Records data;

- Data export and printing;

- Creates charts;

- Displays information about the car;

- Measures acceleration time and power;

- Much more...

The adapter supports the following OBD II/EOBD protocols:

ISO15765-4 (CAN)

ISO14230-4 (KWP2000)

ISO9141-2

J1850 VPW

J1850 PWM

• In more detail :

SAE J1850 PWM(41.6 kbaud)

SAE J1850 VPW(10.4 kbaud)

ISO 9141-2(5 baud init, 10.4 kbaud)

ISO 14230-4 KWP(5 baud init, 10.4 kbaud)

ISO 14230-4 KWP(fast init, 10.4 kbaud)

ISO 15765-4 CAN(11 bit ID, 500 kbaud)

ISO 15765-4 CAN(29 bit ID, 500 kbaud)

ISO 15765-4 CAN(11 bit ID, 250 kbaud)

ISO 15765-4 CAN(29 bit ID, 250 kbaud)

SAE J1939

Programs for the Symbian system (S60):

1. OBD Scope v.1.21

2. OBD Scope v.1.6

Programs for the PalmOS system:

1.OBD Gauge

2. PDADyno (Demo)

This equipment supports the following car brands::

Acura, Alfa Romeo, Ariel Atom, Aston Martin, Audi, Bentley, BMW, Buick, Cadillac, Chevrolet, Chrysler, Citroen, Daewoo, Daihatsu, Daimler, Dodge, Ferrari, Fiat, Ford, Geo, GMC, Holden, Honda, Hummer , Hyundai, Infiniti, Isuzu, Jaguar, Jeep, Kia, Lamborghini, Lancia, Land Rover, Lexus, Lincoln, Lotus, Maserati, Mazda, McLaren, Mercedes, Mercury, MG, Mini, Mitsubishi, Nissan, Oldsmobile, Opel, Pagani, Panoz, Peugeot, Plymouth, Pontiac, Porsche, Regal, Renault, Rolls-Royce, Roush, Rover, Saab, Saleen, Saturn, Seat, Scion, Shelby, Skoda, Smart, Subaru, Suzuki, Tesla, Toyota, Triumph, TVR, Vauxhall, Volkswagen, Volvo, Yugo.
